Daat Research Corp. announces new solution visualization tools for its award winning Coolit family of CFD thermal software for electronics. The new tools will help engineers better appreciate the implications of their design decisions and guide them toward design optimization. One new tool is solution volume visualization using color fog. Typically, fog depicts temperature or pressure variations and its opacity can be controlled, allowing the user to view obscured objects. When combined with sectional view planes, fog helps the user to quickly analyze complex spatial distributions. A second powerful tool being introduced is automatic flow visualization and animation. Based on previously available streamrods and streamribbons, the new one-click option automatically distributes injectors throughout the solution field and injects particles that show flow direction, velocity, swirl, as well as the local value of a scalar variable, such as temperature, at the particle's location. In addition to the shared improvements, each Coolit member delivers a unique new feature. Coolit v.11 implements major improvements in its CAD models import capability. Figure 1. shows the computed results of the new import in a real-life geometry. Meanwhile, CoolitPCB v.7 adds several new components to its library, such as triangular prisms and inclined baffles. These components will expand the software's range of possible applications. For further information on Coolit products, please visit www.daat.com or email info@daat.com .
Figure 1: Coolit v.11 creates realistic thermal models, such as this heat exchanger and baffle (blue), from CAD imports. About Daat: Founded in 1992, Daat concentrates on the development of top-performing computational
fluid dynamics (CFD) products for MS Windows. Daat's award-winning Coolit family of CFD products is available across all Windows
platforms and is well-regarded for its remarkably intuitive user interface, a full range
of Windows capabilities, and exceptionally fast solution times that are particularly
valuable for what-if analyses. ### Note to Editors: To retrieve Daat press releases via fax, please call
